You will find the specifications of the RSA3000E series Open PDF

#Rigol dsa815 reference measurement generator

#Rigol dsa815 reference measurement full

The RSA3015E have RBW settable down to 10 Hz, a DANL (displayed average noise level) down to -161 dBm (typical) and a 1ms Full Span Sweep in its general-purpose spectrum analyzer mode.ĮMI filter and detector such as 9KHz, 120kHz and Quasi-Peak as example are standard.Įxtendibility: Pre-Amplifier, High Stability Clock, Advanced Measurement Kit, EMI Pre-compliance Test Software can be added optional. The new spectrum analyzer offers the ability to trigger and capture signals by 100% if longer than 7.45 µs in duration. The Real-Time-Bandwidth of 10 MHz and the Frequency-Mask-Trigger let you visualize, isolate and capture signals to analyze their behavior over amplitude, frequency and time. The RSA3015E family features a 10.1” touchscreen display, compact design and easy-to-use interface and operations, making it ideal for benchtop or field apps in RF and wireless testing and production such as IoT, RFID, analog and digital modulated signals.Įmbedded-System-Designer can cross trigger and analyze bus signals like IC2, SPI with RF Signals. Rigol's new RSA3015E series spectrum analyzers redefines the product category of general purpose spectrum analyzer by adding Real-Time spectrum trigger and analysis capabilities and sets a new level performance and price. The RSA3015E combines industry leading Realtime performance (7.45µs 100% POI), rich data displays, and advanced triggering options allowing the user to quickly capture, identify and analyze these complex events. Real-Time Spectrum Analyzers bring the dimension of time to RF Analysis making it easier to monitor and characterize these complex RF systems. Engineers integrating WiFi, Bluetooth and other modern RF technologies are confronted with complex challenges like frequency hopping signals, channel conflict, and spectrum interference. The Rigol RSA3015E is a compact and light weight spectrum analyzer series with premium performance standard spectrum analysis capabilities combined with a Real-Time Spectrum Analyzer which makes it possible to never miss any signal that is longer than 7.45 µs in duration. The menu navigation is very intuitive and all functions and parameters are easy to locate thanks to the graphical interface. The Rigol Spectrum Analyzers have a sophisticated and easy to use user interface offering multiple functions for all tasks.

#Rigol dsa815 reference measurement manual

These functions enable the analyzer to acquire signals and match parameters automatically, compared to the manual process necessary with a traditional analyzer. The very large display (20.3 cm / 8") of the Rigol DSA815 Spectrum Analyzer provides a resolution of 800x480 pixels allowing a very good overview of all its comfortable functions like Auto Tune, Auto Range, Auto Scale and Auto Couple. The use of digital IF (intermediate frequency) technology guarantees reliability and performance to meet the most demanding RF applications.

#Rigol dsa815 reference measurement portable

The Rigol DSA815 is a compact and light weight Spectrum Analyzer with premium performance for portable applications. GW Instek provides the most cost-effective options in RF measurement. The most common interfaces including LXI are included designs for remote control. The sequence function allows to create and perform a series of measurement steps without connecting to PC. The SEM, ACPR, OCBW, CNR, CTB, CSO measurements, 1Hz marker frequency counter and many other measurement functions are provided as well. The topographic and spectrogram display modes are developed to paraphrase the signal in color temperature pattern to perform the signal persistence and time progress. The 0.025ppm frequency stability over temperature is employed, integrating with high efficient heat dissipation mechanism, to sustain the stable and accurate measurement. There are many features are designed to perform higher stability measurement, further signal analysis and more efficient measurement. Spectrum analyzer lineup fits a broad range of applications in research and design, service and maintenance, manufacturing, educational and other related fields for the frequency range from 500MHz to 7.5GHz.
